- Socket: LGA1700 hỗ trợ CPU intel thế hệ 12
- Kích thước: Micro ATX
- Khe cắm RAM: 2 khe (Tối đa 64GB)
- Khe cắm mở rộng: 1 x PCI Express x16 slot, running at x16; 1 x PCI Express x1 slot
- Khe cắm ổ cứng: 1 x M.2 connector, 4 x SATA 6Gb/s
Còn hàng
2.990.000 đ
1.690.000 đ
Nhóm thuộc tính của Mainboard | |
Thương Hiệu | GIGABYTE |
Model | H610M S2H DDR4 |
Kích Cỡ | Micro ATX Form Factor |
CPU Socket | LGA1700 |
Chipset | Intel |
Số Khe Ram | 2 |
Bus Ram Hỗ Trợ | Support for DDR4 3200/3000/2933/2666/2400/2133 MHz memory modules |
Dung Lượng Ram Tối Đa Hỗ Trợ | 64GB |
Số Kênh Bộ Nhớ Hỗ Trợ | Dual channel |
PCI Express 3.0 x16 | 1 x PCI Express x16 slot, running at x16 |
PCI Express x1 | 1 x PCI Express x1 slot |
Số Cổng SATA | 4 x SATA 6Gb/s connectors |
M.2 | 1 x M.2 connector (Socket 3, M key, type 2260/2280 PCIe 3.0 x4/x2 SSD support) |
LAN Chipset | Intel® GbE LAN chip |
Tốc Độ LAN | 1 Gbps/100 Mbps |
Cổng I/O Phía Sau | 1 x PS/2 keyboard port 1 x PS/2 mouse port 1 x D-Sub port 1 x DVI-D port 1 x DisplayPort 1 x HDMI 2.0 port 2 x USB 3.2 Gen 1 ports 4 x USB 2.0/1.1 ports 1 x RJ-45 port 3 x audio jacks |
Onboard USB | 1 x USB 3.2 Gen 1 header 2 x USB 2.0/1.1 headers |
Cổng Kết Nối Khác | 1 x CPU fan header 2 x system fan headers 1 x front panel header 1 x front panel audio header 1 x Trusted Platform Module header (For the GC-TPM2.0 SPI/GC-TPM2.0 SPI 2.0 module only) 1 x serial port header 1 x Clear CMOS jumper |
Đèn LED Đi Kèm | 1 x RGB LED strip header |
Kích Thước (W x L) | Micro ATX Form Factor; 23.0cm x 21.5cm |
Chân Cắm Nguồn | 1 x 24-pin ATX main power connector 1 x 8-pin ATX 12V power connector |
